Beam Elements under Enforced Displacementĩ. FEA Modeling of the Bent Rod with Beam ElementsĨ. C-clamp Deformed with Enforced Displacementħ. Deformation of an I-beam under Self-weightĦ. Axially Loaded Block with Stress Concentrationĥ.
Analysis of a Bent Rod with Solid Elementsģ. Typically, the differences are not even noticed by a beginner.Ģ. The tutorials are based on release 21 however, other releases can also be used with minor changes. However, it is assumed that the user is familiar with CATIA V5 Release 21 interface and basic utilities such as pan, zoom, and rotation. The reason behind the simplicity is not to burden the reader with the CAD aspects of the package. In this workbook, the parts created in CATIA are simple enough they can be modeled with minimal knowledge of this powerful software.
However, the best strategy to learn is to sequentially cover the chapters. The chapters are designed to be independent of each other allowing the user to pick specific topics without the need to go through the previous chapters. The objective of this tutorial book is to expose the reader to the basic FEA capabilities in CATIA V5 Release 21.
Introduces new users to the Finite Element Analysis capabilities of CATIA 21.
